Cudy BE6500 Gigabit Wi-Fi 7 Router - WR6500

Technical Specifications

CategoryDetails

Model Version

WR6500 1.0

CPU

Broadcom BCM6766, 2.0 GHz Quad-core ARM Cortex-A7

Memory/Storage

Flash: 128 MB NAND; DDR: 512 MB DDR4

Wireless Speed

5 GHz: 5765 Mbps; 2.4 GHz: 688 Mbps

Wi-Fi Standards

Wi-Fi 7 (4K-QAM, MLO, MU-MIMO, OFDMA, BSS Color)

Wi-Fi Streams

5 GHz: 4T4R (4×4 MIMO); 2.4 GHz: 2T2R (2×2 MIMO)

Antennas

6 Fixed Antennas (5 GHz Max Gain: 5.27 dBi; 2.4 GHz Max Gain: 5.19 dBi)

Beamforming

Supported

Ethernet Ports

5 Gigabit RJ45 Ports (1 WAN + 4 LAN)

Coverage Area

Up to 140 m² (1,500 ft²)

Max Connected Devices

Recommended: Up to 200; Max Capacity: Up to 512

Power Supply

Input: AC 100-240V; Output: DC 12V/1.5A

Max Power Consumption

17W

Operating Temperature

0°C ~ 40°C (32°F ~104°F)

Certifications

FCC, CE

Installation Options

Desktop or Wall-Mount

Dimensions & Weight

Product: 253×152.5×48.2 mm (9.96×6×1.9 inches); Weight: 580 g (20.46 oz.)
