Ubiquiti USW-16-POE

Ubiquiti • Networking

Ubiquiti USW-16-POE

Product introduction:

  • The USW-16-POE is a configurable Gigabit Layer 2 switch with sixteen Gigabit Ethernet ports including eight auto-sensing 802.3at PoE+ ports, and two SFP ports.
  • It provides Gigabit PoE links to your RJ45 Ethernet devices and Gigabit fiber uplink options to your enterprise network. The USW-16-POE features a 1.3" touch LCM to provide status information.
  • With a depth of 7.9", the compact fanless design can be easily installed in a SOHO rack cabinet.
  • Managed and configured by the UniFi Network Controller with UniFi mobile app support, the USW-16-POE offers an extensive suite of advanced Layer 2 switching protocols and features, including operation mode (switching, mirroring, or aggregate) per port.
  • The UniFi Network Controller and mobile app allow admins to configure and monitor virtually all of the switch features in a graphical user interface from anywhere.
  • Manufacturer: Ubiquiti Networks, Inc.
  • Manufacturer Part Number: USW-16-POE.
  • Brand Name: Ubiquiti.
  • Product Line: UniFi.
  • Product Model: USW-16-POE.
  • Product Name: UniFi 16-Port PoE Switch.
  • Product Type: Ethernet Switch. [Interfaces/Ports] Total Number of Network Ports: 16.
  • Uplink Port: Yes. Modular: Yes.
  • Port/Expansion Slot Details: 8 x Gigabit Ethernet PoE+. 8 x Gigabit Ethernet Network. 2 x Gigabit Ethernet Expansion Slot. [Media & Performance]
  • Media Type Supported: Twisted Pair. Optical Fiber.
  • Ethernet Technology: Gigabit Ethernet.
  • Network Technology: 10/100/1000Base-T. 1000Base-X. [I/O Expansions]
  • Number of Total Expansion Slots: 2. Expansion Slot Type: SFP (mini-GBIC).
  • Number of SFP Slots: 2. [Network & Communication]
  • Layer Supported: 2. [Management & Protocols]
  • Manageable: Yes. [Power Description]
  • Power Source: Power Supply. [Physical Characteristics] Compatible Rack Unit: 1U.
  • Form Factor: Rack-mountable.
  • Desktop. Height: 1.7". Width: 17.4". Depth: 7.9". Weight (Approximate): 6.

Product Highlights:

  • Total Number of Network Ports: 16
  • Uplink Port: Yes
  • Modular: Yes
  • Port/Expansion Slot Details: 8 x Gigabit Ethernet PoE+
  • Port/Expansion Slot Details: 8 x Gigabit Ethernet Network

Product key features:

  • 16 x Gigabit Ethernet Ports
  • 8 x PoE-Compliant Ports
  • 2 x Gigabit SFP Ethernet Ports
  • 36 Gb/s Switching Capacity
  • 78 Mpps Forwarding Capacity
  • Rack-Mountable Design
  • 3" Touchscreen Display
  • Passive Cooling
  • UniFi Controller Support.
